2500 UT Unitwall® System

The 2500 UT Unitwall® System combines the elegant aesthetics of a unitized curtain wall with ultra-thermal performance. The unitized framing system reduces installation time and is ideal for commercial applications and mid- to high-rise projects.

  • 2-1/2″ (63.5mm) sightline
  • Standard infill options: 1/4″ (6.4mm), 1″ (25.4mm) and 1-3/4″ (44.5mm)
  • 7-1/2″ (190.5) captured and 6-1/2″ (165.1mm) 4-sided SSG/SGT depth in 1″ (25.4mm) infill
  • 8-1/4″ (209.6) captured and 7-1/4″ (184.2mm) 4-sided SSG/SGT depth in 1-3/4″ (44.5mm) infill
  • Ultra-thermal performance
  • Mid- to high-rise applications
  • Seismic (AAMA 501.4 and 501.6 standards)
  • Continuous polyamide thermal break for ultra-thermal performance
  • Provides ultra-thermal performance in a cost-effective unitized curtain wall system
  • Unitized construction to accelerate installation and minimize disruption to the surrounding area or existing tenants
  • Four-sided captured system allows for crisp sightlines
  • Four-sided SSG option delivers seamless transition between units
  • Structural silicone glazed (SSG) options
  • Structural glazing tape (SGT) configurations
  • 2-sided SSG and SGT option available
  • 1″ (25.4mm) and 1-3/4″ (44.5mm) insulating glazing spandrel

Awards and Recognitions

  • Architectural Systems and Facades Category Winner, Metropolis Planet Positive Awards 2022

Optional Features

  • Steel reinforcement
  • Profit$Maker® Plus die sets
  • Dual-color option

Thermal Technology

Find out more here.
